Model No.:XC-1-2
Product Origin:China
Brand Name:Like
Price Terms:
Payment Terms:T/T
Certification:
Description:Product Name: Reduction GearModel Number: XC-1-2Place of Origin: ChinaSpecifications:1) Produce according to the paper given2) Basic parameters:a) Ratio of transmission: 1:3714 (output axle 1, output axle 3.714)b) Gear: 0.75c) Medium gear: 28d) Small gear: 24e) Big gear: 763) Lubricate: a) Oil seal of gear box is coated with lubricating oilb) The connection of transmission gear is coated with lubricating oil at least 10g4) Noise: being equipped, the noise of unload should be less than 50Db5) Life span: being work 5,000 times continuously under the standard load (6.8kg) (the timer routine is cleaned once every 15 min.)6) Material: a) Output axle: 2Crl3b) Input axle: no.45 steelc) The under covered bearing of gearbox is oil one7) The output water seal of gearbox applies the bilateral seal, according to the standard GB9877.1-888) The mouth of the water seal is coated with lubricating oil9) Dimensions are according to the paper given10) Quality of outline: clean, no dirties; with the same color, no motley; no rustspot in the input axle and covered with safeguard case out the output axle;intact package and no damage
