HR series helical gear reducer
Ratio:3.4~280.6(up to 23717 by combination)
Power range:0.12~160KW
Output torque:110~15300N.m
Output form:solid shaft
Input form:direct connection with motor,flange for mounting motor,solid shaft(coupling,belt drive,chain drive)
Mounting position:foot mounted,flange mouted(refer to the catalague for different flange size)
HS series helical-worm gear reducer
Ratio:7~291.4(up to 32625 by combination)
Power range:0.12~22KW
Output torque:37~3400N.m
Output form:solid shaft,hollow shaft(Parallel key,Shrink Disc,Splined hollow shaft)
Input form:direct connection with motor,flange for mounting motor,solid shaft(coupling,belt drive,chain drive)
Mounting position:foot mounted,flange mouted,torque-arm mounted,small flange mounted
HF Series parallel shaft helical gear reducer
Ratio:3.71~279.9(up to 30264 by combination)
Power range:0.12~200KW
Output torque:110~15300N.m
Output form:solid shaft,hollow shaft(Parallel key,Shrink Disc,Splined hollow shaft)
Input form:direct connection with motor,flange for mounting motor,solid shaft(coupling,belt drive,chain drive)
Mounting position:foot mounted,flange mouted,small flange mounted
