Feature:

1.Use the arc-shaped arch-plate chain ,so that the chain on the board is expected to reduce the damage;

2. Load can reach 20-50 t,with large, high-intensity silo;
3. Prevent skidding;
4. Uniform feed rate;
5. Easy to clean up;

The main technical parameters:
Length: 7184 mm
Width: 2500 mm
Height: 3760 mm
Whole weight: about 7.5 tons
The largest whole volume: 17 cubic meters
Electric power: 3 kilowatts
The speed of transmission chain plate: 1.3 m / min
The largest volume: 25 cubic meters / hour (about 40 tons / hour)
Note:It is related to the distance of the materials, the dryness of  the porcelain clay and the proficiency of operations

Accessories list:
1. Feeder rack  (1set)
2. Silo (a set )
3. Feeder transmission (1 set)
4. Bridge load cell (4 sets)
5. Weighing Instrument (a set)
6. 3-inch large screen (a set)
7. Data-transmission cable signal (a set)
8. Junction Box (a set)
