Product Description

The idea machine suitable for making spiral tube, pipe, duct widely used in all kinds of industrial.
Main Technical Specification:
-Finished Product Diameter 80 - 1600mm

-Material Thickness:0.4-1.3mm  (Glvanized steel)
                    0.8mm (Sinless steel)
                    0.4-1.2mm( Auminum)

-Material width: 1-137mm
-Cutting way:fly slitter

-Lock Way: Outer round or inner according to request

-Max.speed:60m/min
-Machine weight:3200kg

-Machine dimension(LxWxH):3000*1950*1700mm
