Model:YN/YY60-100
You benefit:
Small size, light weight, super low noise, high strength material, easy installation and maintenance. It can be designed as customers' request. It is suitable for various mechanism equipment.
Motor Specification:
| Three Phase Gear Motor | Single Phase Gear Motor | |
Three Phase Gear Motor | Gear | All built-in gears are high precision processed by high grade special alloy steel and through carburizing and quenching. | |
Material of gear case | Alloy steel moulded shapement (shaft dia. 18,22,28), cast iron moulded shapement (32,40,50) | ||
Lubrication | The machine is injected with high class lubrication inside when dispatched, so no need to add. | ||
Motor | Power | 220/380V | 110/220V |
Frequency | 50/60Hz | 50/60Hz | |
Cooling type | Fully-enclosed external fans | ||
Starting type | Directly starting under total pressure | Continuous rotation starting, Capacitor starting | |
Housing material | Superb alum alloy stainless steel | ||
Insulation degree | F, B degree | ||
Protective degree | IP54 for Aluminum junction box, IP20 for Steel junction box | ||
Brake | Working mode | No excitation magneto type brake (Power interrupt brake) | |
Voltage | DC90-110V attached AC220V,AC110V rectifier | ||
Common Environment | Temperature | -10 ~ +40 centigrade | |
Humidity | Below 90% (noncondensable) | ||
Site | Indoor, the altitude below 1000m | ||
