Features:
The capacitor takes heavy-edge metallized Al/Zn film as electrodes and dielectric. The elements are tight winded by high-velocity winders and canned in aluminum cases. Refined castor oil is adopted as impregnation agent treated in vacuum and high temperature condition. Those make a more reliable performance and longer lifespan for a capacitor. Meanwhile the second generation of mechanical anti-explosion design is selected as blast-proof secure measure for our capacitors. The reliability is more affirmatively enhanced.

Applications:
Broadly applied to starting and running of AC single-phase motors at 50Hz(60Hz) frequency for family air conditioners and high power illuminators for the sake of power factor compensation.

Technical Specifications:
  Standard:IEC 60252-1:2001
  Climate type:40/70/21 or 40/85/21
  Capacitance tolerance:± 5%
  I.R:≥3000S(MΩ·μF)
  Dielectric dissipation factor:tgδ≤0.002 (50Hz~100Hz)

Application requirements:
  Altitude:≤2000m
  Residual voltage while loading: less than 10% of rated voltage.
  Allowed maximum voltage: less than 1.1 times of rated voltage
  Permissible maximum current: less than 1.3 times of rated current.
