Brand:Catsu
Model:CT02
Send Inquiry
STRATEGIC MEASUREMENTS *
| Width A: (mm) | 180 |
| Width B: (mm) | 155 |
| Width C: (mm) | 160 |
| Total length D: (mm) | 435 |
| Build height E: (mm) | 245 |
| Weight: (kg) | 35 |
| Tilt: | 2x40 |
| Flow requirement: l/min | 15.5 |
| Work pressure: (Mpa) | 18.1 |
| Max. return pressure: (MPa) | - |
| Standard mountings: | S30, S40 |
TECHNICAL INFORMATION *
| Machine weight: (tonnes) | 1.5-3 |
| Rotation: | Infinite |
| Oil flow: (l/m) | 15.5 |
| Rotation at 50 l/m: (rpm) | - |
| Rotation torque: (kNm) | - |
| Breakout force max.: (kNm) | - |
| Swivel, extra: | - |
| Double swivel: | - |
| Oil flow max.: (l/m) | - |
| Extra hydraulic coupling, hitch: | - |
