Brand:Quansel
Model:POM sheet
Quansel Acetal POM sheet
Thickness:5mm~160mm
ColorsInclude:
-Natural (white), Black, other colors
| Thickness | Width/Length |
| 0.3--1.5mm(in roll) | W:700mm,any length |
| 2--5mm | 700mm x1200mm |
| 6--12mm | 600mm x1200mm |
| 15--100mm | 1000mm x2000mm |
| 110mm –200mm | 600mm x1200mm |
Remarks:
---Othersizes, colors can be customized.
---Length, width,and thickness tolerances may vary by manufacturer
---Certain gradesavailable in various colors.
---Minimums mayapply to certain materials
I. POM Sheet Description
Good mechanical properties and rigidity, and close to themetal material. It’s an ideal replacement material of copper, cast zinc, steel,aluminum and other metal materials. Excellent fatigue resistance and creepresistance. Good abrasion resistance, self-lubricated and friction. POMtogether withUHMWPE,PA, F4 are known as the four wear-resistantplastic materials. High thermal stability, good chemical stability andexcellent electrical insulation.
II. POM Sheet Characteristics
Advantages:
? High surface hardness and surface density.Small abrasion consumption,impact fatigue and shock resistance,
small coefficientfriction, and self-lubricating, therefore, it is the first material choice formanufacturing gear.
? High mechanical strength and rigidity. Although the contraction rate ishigh, the dimension is stable.
? Good dielectric properties, solvent resistance, non-stress cracking.
? Torsional resistance, it can be restored to their original when removed theexternal force.
Disadvantages:
? Poor acid resistance
? Poor dimensional stability
? Weatherability is not excellent especially the UV
III.POM Sheet Processing Solution
Available for injection molding, extrusion, blow molding and secondprocessing etc.
IV. POM SheetApplications
? Machinery industry used toproduce gears, springs, bearings, connecting rod, impeller blades etc..
? Automobile industry
? Electronic and electrical appliances
? Others, such as toys, windows, water tanks and washingbasins
NOTE: For POM propertiesdata sheet, please visit our technical resource section. Several grades of POMare available. For additional information on POM plastic materials, contact QuandaPlastics representative or call QUANDA at 0086-(0)755-28113160.
