Key Specifications/Special Features:

Integrally cast lathe bed, robust and without distortion.
3 axes transmission with imported ball screws ensures stable and smooth movement of the machine.
Application of driver with high definition subdivision ensures fast speed and high accuracy.
High power spindle, brushless, water cooling, working vigorously with low noise, guarantees long time mass processing.
Optimized mechanical and electrical design with well-selected brand parts minimizes breakdown rate.
Humanized design enables easy disassembly of the machine for convenient transportation.

Welded structure of thick profiled steel and inner stress removed by vibration ageing treatment, strong lathe bed makes the machine with rigidity, no distortion.
Y axis driven by double motors, high accuracy rack gears transmission, powerful and stable movement.
Up-down working table with 2 KW 3 phase asynchronous motor; Gearbox with worm and worm wheel transmission drives chain wheel with large pitch and 4 ball screw;
Working table rises and falls on 4 guiding cylinders firmly and smoothly
Maximum lifting weight is up to 1500 KGS.

Rotary attachment with chuck and dead center moving on linear square rail with high precision concentricity.
Chassis is made with L -102 integrally cast technology
Maximum work piece diameter 400mm, and the length up to 1200mm, weight of 56KGS and collocated with balance trolley.
Options: Stainless steel tank for processing stones and configured with auto water supplying device as well.
2 rotary attachments model 4021 can be fixed to the working platform.

Specification:
Multiple Spindle, with rotary and up-down table
Working Area: 1, 100 x 1, 800 x 180mm
Max Moving Speed: 6, 000mm/min
Reposition Accuracy: 0.02mm
Transmission: imported Ball Screw
Operation System: DSP Controller
Voltage: AC220V/50/60Hz
Packing Size: 2, 400 x 2, 100 x 1, 500mm
