1) Machine size: 1, 800x 1, 380mm
2) X-Y-Z axis working area: 1, 200 x 1, 500x 100mm
3) X-Y-Z movement: Rack gears on linear rails
4)Max. Motion speed: 25, 000mm /min
5)Max. Cutting speed: 20, 000mm /min
6) Repeatability: 0. 01mm
7) Spindle: 1. 2Kw, water cooling, 6, 000-24, 000rpm
8) Drive motors: Stepper
9) Working voltage: AC 220V-240V/50-60Hz
10) Command code: G code
11) Collet: 3. 175mm 4mm, 6mm
12) Software: Type3 Software (Original English Version)
13) Controls: PC to Router, Command Control
14) Packing dimensions: 1, 700x 2, 100x 1, 500 mm, 450 Kg
