Advertising signmaking: Large word engraving, signmaking, LED/slot of neon light, hole shape cutting, mould making and so on.

Features
The spindle are controlled by software, high automazation
High speed and high efficiency, idle speed can reach up to 14 meters/min.
Big power, high quality steel
Double motors driving, unique two-rack axises to transimit the machine, so it can guarantee no distortion and vibration when it works for long time.

Technique Parameter
Description Parameter
X and Y working area 1300 by 2600mm
Z working area >100mm
Table size 1400 by 3000mm
Max. Speed 14m/min
Max. Working speed 12m/min
Max. Feeding height 120mm
Work accuracy 0. 005mm
Repositioning delicacy 0. 05mm
Command G code*. U00*. Mmg*. Plt
Surroundings for software windows98/2000/xp
Power (spindle is not included) 1500w
Work voltage AC220V/50Hz
Spindle power 2. 2kw
Spindle rotating speed 24000rpm/min
Drive motor Steper
Weight 700kg
