1. Application:
HJ508 Ring Spinning frame is suitable for spinning of cotton, synthetic fiber or their blends. With ball bearing, the transmission system adopts structure of bevel gears. The machine is reliable and convenience for maintenance, which ensures high quality yarn spinning.

2. Specification:
Spindle gauge: 70 mm
Lift: 180, 250 mm
Ring diameter: Φ 38, Φ 40, Φ 42, Φ 45 mm
Yarn count: 5.83-58.3 tex (10-100 Ne)
Twist: 300-1800 per meter
Spindle speed: 12000-20000 r/min
Draft ratio:
Total draft: 10-50
Rear draft: 1.05-1.5
Twist direction: Z twist, S twist
Draft system: 3 line roller, double aprons, pendulum arm weighting
Roving creel: Bobbin hangers of six rows or four rows single tier.
