Features:
1. Suitable for diversified and complex processing, widely used for carving, drilling, cutting, side milling, guiding edge, and mainly used for cutting and wood routing.
2. German-imported vacuum System, Japan-imported servo driving system, High frequency Italy-HSD spindle.
3. Cloak style automated ATC system, 8 knives in storeroom, just 8 seconds per change.
4. Double rails with double sides driving system.
5. Strong vacuum absorption for woodworking mould
6. Processing speed can be up to 25M/min.
7. CE certification

Applicable Industries & Materials:
Furniture industry, solid wood furniture, solid wood doors, decorative materials, computer tables, panel furniture, office furniture, wooden speaker and kitchenware, etc. It also takes automobile mould and non-metallic mould.

Technical Performance:
Machine name: ATC TK-1224 Woodworking Centre
XYZ Guide rail: Square Rail
X, Y Transmission: Rack Gears
Spindle motor: HSD 8KW
Software: TYPE 3 / ARTCUT(English)
Operation System: SYNTEC
Driver: Stepper Motor(YAKO)
Spindle speed: 0-24000 RPM
Max Working Speed: 25000mm/min
Working voltage: AC380/50Hz
Blade Diameter: 3.175mm, 4mm, 6mm(or 8mm, 12mm, 12.7mm)
Working Size: 1200*2400mm
X, Y, Z Repositioning Positioning Accuracy: 0.05mm
X, Y Resolution: 0.02mm
N. W: 2000KG
G. W.: 2300KG
Delivery Date 25 working days

Guarantee and After-sale service:
1)1 year guarantee
2)Offer 24 hours technical support and e-mail or calling
3)Use the English manual friendly and can refer to the Video CD for to know the machine using and maintaining.
