Nominal pressure rating: 0.6Mpa 1.0Mpa 1.6Mpa 2.5Mpa 150Lb
Nominal diameter: DN50~2000mm nps 2"~80"
Suitable temperature: -38~+1100C
(Range of temperature subject to the material of sealing and property of medium)

Connecting flange: ANSI B16.5GB/T9113GB/T79HGSHJIS DIN NF BS
Main materials: C. I WCB ZG1Cr18Ni12Mo2TiCF8CF8MCF3CF3M2Cr25Ni20
Seal type: Stainless steel hard seal: Teflon soft seal
Leakage: Stainless steel hard seal: Grade D(Liquid 0.1XDNmm3/s)
Teflon soft sea: Grade A (Zero Leakage)Accessories: Flange.
