For installation in the winch drum of all kinds of hoisting gear, e. G. In mobile and crawler cranes, in railway cranes, in deck, harbor and container cranes.
Output torques from 9.5 to 275 kNm
Cable forces from 50 to 595 kN
Ratios from 16.3 to 302.4

Featurs:
Compact two- or three-stage planetary gearboxes
Robust bearing to accommodate the rope pull force
Cageless planetary gear bearing
Optimized seals
Integrated multi-disc parking brake
Optional with A2FM/E fixed motor or A6VM/E variable motor available
Easy mounting
Easy oil change
Low-noise operation
