Product Overview
SO910 - Ⅲ-bearing vibration measuring instrument for the acceleration of dB value. Instrument performance mainly reflected in our use more advanced design to:
1, a hybrid spindle to spindle structural design work in a totally suspended state, and spindle bearings never wear, no friction noise unlimited service life extension.
2, rotation accuracy higher (≤ 0.002) test no other factors involved in error detection Bearing in itself.
3, both in indoor temperature of any state use of equipment will not affect the accuracy and performance, no need for heating in winter will never have a hold axis phenomenon.
4, bearing different noise in the test collection and distinguish more clearly intuitive.


Main Specifications

1, measured bearing type: deep groove ball bearings, single-sided angular contact bearings.
2, the measured bearing specifications: (diameter) Ф6-Ф60 mm
3, the measuring range: RMS :0-40 between 30-70 60-100 dB; 3 optional
Peak :15-55 ,45-85 ,75-115 dB; 3 optional
4, a consolidated basis Vibration: ≤ 2 dB
5, integrated rotation accuracy: ≤ 0.002
6, the axial thrust: 2 to 5 kg adjustable
7, Spindle Speed: 1500 r / min ± 15r/min
8, oil pressure: 0.6 MPa
9, available power: 380 V, 50Hz (370W three-phase motor-2)
Xinhua me power: 220 V ± 10% 50Hz 80W
10, lubricating medium: on the 2nd spindle oil
11, Weight: 225 kg ≈
