Model:KH
AAC block making machine:
Cutting machine is the main equipment of AAC block making machinery as well as the core machine of AAC production line with annual production capacity over 5000m³.It’s the necessary equipment to improve yield and quality. JQF Series Cutting Machine we produce can turn the blank twice, and do the six-side cutting. Weigh the high technology, the turnover can be finished only by one time, which protects the blanks from damage due to many times’ lifting. Our products are sold well in our country and gained honor from many customers. After many years’ technical reform, now we have developed many models of concrete cutting machines.
Main technical parameters:
NO. | Model | Rough before Cutting(mm) | Cutting cycle | Capacity(m³/year) | Cutting Precision(mm) | Total Power | Dimension(mm) |
1 | 4.2m | 4250*1240*650 | 6-8min/mold | Above100000 | Six-side cutting≤±3.1.1 | 25.5KW | 12200*4200*5600 |
2 | 4.8m | 4860*1560*650 | 6-8min/mold | Above 200000 | Six-side cutting≤±3.1.1 | 30KW | 16000*6000*5500 |
3 | 6.0m | 6050*1540*650 | 6-8min/mold | Above 200000 | Six-side cutting≤±3.1.1 | 30KW | 18500*6000*5800 |
Turnover cutter in our factor has following advantage:
1. Compact structure, easy to operate and little maintenance.
2. Cross cutting and vertical cutting finished once.
3. Six sides cutting of the blank, product precision in accordance with GB/T 11969-1997.
4. All waste materials shall be reclaimed, by which secondary pollution will not be resulted in.
5. Blank are not conglutinated.
6. With equipments to replace steel wire rapidly.
7. No crack phenomenon.
