Aluminum foil container making machine CTJF-45T

Aluminum foil container making machine CTJF-45T has been designed and developed as an upgraded model to produce aluminum food containers, dishes and trays. The working speed of production line CTJF-45T is 40-70 pcs/min (with one cavity mould), and its speed depends on container’s size and complexity.

Aluminum foil container making machine CTJF-45T is composed of the followings:

1.      Decoiler (with an auto-lubricator)

2.      Electrical control panel

3.      Air output control equipment

4.      40 ton pneumatic press

5.      Mould

6.      Conveyor(including scrap collector)

7.      Collection desk

Main Features:

(1)   This production line can work automatically. Worker control and regulate this production line through electric control equipment.

(2)   The width of decoiler is about 520mm.

(3)   The feeding system control feeding length and stepping by computer, which assure a high-precision steps.

(4)   We can design and manufacture different machines on request. There is some difference in machine’s outer-appearance.

(5)   The press may be equipped with single cavity or multi-cavity moulds for wrinkle-wall or smooth-wall container production.

The working flow of production line CTJF-45T:

Aluminum foil roll ---decoiler---air output control equipment---45T pneumatic press---mould---conveyor--- collection desk---packing

This production line is most popular during our customers,. We sell this production line to many countries, such as Algeria, Turkey, Saudi Arabia, and so on. Its speed is fast, and with high precision and high safety,
