Model

DR1800FZ-PL/B

Wrap size (L X W)

(500-1300)mm X (500-1200)mm

Wrap height (max)

1800mm

Rotary speed

Standard

0-15rpm adjustable    >30 Pallets/Hour

High  speed

0-25rpm adjustable    >45 Pallets/Hour

Super speed

0-35rpm adjustable    >60 Pallets/Hour

Film carriage

Power pre-Stretch system up to 350% with adjustable speed

Cut & clamp unit

Pneumatic

Pneumatic system

0.6-0.8Mpa,1000ml/min

Lift system

Lift speed adjustable

Conveyor

Height:400mm  Speed:8-15m/min  Load-bearing:2000kg

Control system

PLC control,wrap layers adjustable,photo-eyes auto-height sensing

Safety system

Grid guard and strike-proof protect system

Machine size (L X W X H)

4000mmX 2000mm X 4300mm(without conveyor)

Power/voltage

Rotary arm:0.75kw  Film carriage:0.37kw  Lift system: 0.37kw/AC380V
