Feature:

Ÿ           Microcomputer controller system, easy operate.

Ÿ           Temperature controller using digital control technology, the setting temperature is more accurate and stable.

Ÿ           Power-off temperature memory system. It can make chillers work at the original temperature once the power is reconnected. Keep plants and animals healthy.

Ÿ           Temperature control can control the high and low pressure of compressor, it will alarm to remind user if pressure too high or too low.

Ÿ           Chiller can work base on the original temperature setting even though the control plate was broke.

Ÿ           Temperature control system with defrost function, it can improve cooling or heating efficiency.

Ÿ           Evaporator is made by top pure titanium tube and advance PVC mold, with strong corrosion resistance ability.

Ÿ           With water shortage protection device. When no water go through the chiller, it will cut off power to protect titanium evaporator and compressor, and save energy

Ÿ           In order to extend the lifetime of machine, chiller will start delay of few seconds.

Technical data

Model voltage Frequency Power Current Cooling capacity Refrigerant Rate of flow Weight Packing size

WN-1C160AN 220~240V 50HZ 1/10HP 1.1 A 50~160L R134A 250~1200L/H 13KG 51*32*47

WN-1C250AN 220~240V 50HZ 1/6HP 1.3 A 100~250L R134A 600~2000L/H 19KG 54*39*54

WN-1C300AN 220~240V 50HZ 1/4HP 1.8 A 100~300L R134A 1000~2500L/H 20KG 54*39*54

WN-1C400AN 220~240V 50HZ 1/2HP 12.4 A 200~500L R134A 1200~3000L/H 18KG 57*42*62

WN-1C500CN 220~240V 50HZ 1/2HP 3.8  A 200~700L R410A 1300~3200L/H 26KG 57*42*62

WN-1C1000CN 220~240V 50HZ 1HP 4.3  A 300~1200L R410A 160~4000L/H 36KG 68*49*73
