Brand:cheuklift
Model:PSS180A
MOQ:1 Sets
Send Inquiry
| Optional configuration - 230V power； - 3m Range of wireless remote control - Kubota Z-482 diesel engine - One or two colors； - Seat belt； - PVC outrigger pedal； - Plastic pedal； - Trailer | ||
| The right of changing specification and design is reserved | ||
| Model | PSS180A | |
| Arm type | crank arm | |
| Working height | m | about 17.90 |
| Platform height | m | about 15.90 |
| Working radius | m | about 7.60 |
| Range of ratation | ∑ | 355 |
| Platform capacity | kg | Max 200 |
| Cage dimensions | m | about 1.2x0.7x1.1 |
| Outrigger size | m | 2.92×3.92 |
| Length | mm | Min 4710 |
| Width | mm | Min 780 |
| Height | m | Min 1995 |
| Pressure on earth(working) | Kn/m | 2 |
| Pressure on earth(traveling) | Kn/m | 3.7 |
| NW | kg | about 2330 |
| Travel speed | km/h | Max 1.5 |
| Motor | Diesel 220V |
