Establish working routine willfully, easy to use. Operating speed stability. Speed smoothing.
1. Technology specification
| Model | CX-18 | CX-12 |
| Production capacity | 3000-6000 b/h | 2000-4000 b/h |
| Bottle neck | Ф50-ф100mm | Ф50-ф100mm |
| Bottle height | 160-320mm | 160-320mm |
| Mainframe power | 0.75kw | 0.75kw |
| Outer size | 1600×1500×1700（mm） | 1200×1100×1700(mm) |
| Machine weight | 1200kg | 800kg |
2. Technology parameter
| Washing medium | Sterile water |
| Washing time | 3s |
| Drying time | 2s |
| Water pressure | 0.2Mpa-0.4Mpa |
3. Operation principle
Conveyor belt will put needed cleaning bottles into the bottle screw , due to the bottle inputting screw and star wheel catch plate are continuously operating in-phase which will synchronously convey the needed cleaning bottles to the center transferring manipulator , and the manipulator along with the rotary table are spraying and washing the needed cleaning bottles , it will revert into the start-off state after completed , then the bottle outputting star wheel catch plate makes the cleaned bottle out , so the whole process is completed .
