Specification:

dielectric material:97 alumina

thickness:3.0mm

dimension:600x100x105(mm)

Discharge gap:

gap:1.2mm

size:￠56x470(mm)

Installation size: （152+152）*91，Ø4(mm)

Refer value for high voltage parameter:

high voltage value:6kv

frequency value:8khz

power consumption:800W

wave: sine wave

Value of ozone production:

production: 12kw.h/kgo3

highest concentration:120mg/L

net weight: 5.68kg

cooling methods: inside water, outside air
