Specification:

1.Size:

power supply230x150x90(mm) , high voltage transformer200x110x98(mm)

2.Weight:

power supply1.25kg, high voltage transformer3.64kg

3.Outpot voltage:

high voltage/frequency:7kv/12khz(adjustable) , power range:0-800W

protection configuration:

1.      high temperature exceed protection

2.      voltage exceed protection

3.      circuit off and short protection

Adjust methods:

manual adjust or PLC0-5V adjust or PLC4-20MA adjust

Working voltage:

AC220V/50HZ(AC110V/60HZ or can be customized)

Application:

driving power supply separate with high voltage transformer; frequency, wave length, output voltage and power limit up and down all can be adjusted; Suitable for less than 80g/h of ozone generator
