Brand:tianyu
Model:5HXG-100
MOQ:1 Sets
Send Inquiry
| 型号 Mode | 5HXG-100 | ||
| 作物籽粒处理量 Grain category and handling capacity(kg) | 稻 Paddy | 1010-10000 | |
| 麦 Wheat | 1230-12000 | ||
| 机体尺寸 Demension of equipment | 全长 Length(mm) | 3360 | |
| 全宽 Width(mm) | 1785 | ||
| 全高 Height(mm) | 7510 | ||
| 机体重量 Weight of equipment(kg) | 1915 | ||
| 送风机 Blower | 种类 Type | 离心式 Centrifugal type | |
| 燃烧器 Burner | 种类 Type | 高压枪式 Type of high pressure gun | |
| 点火方法 Pattern of ignition | 自动点火 Automatic ignition 自动供油 Automatic fuel feeding | ||
| 燃烧量(L/h) Combustion amount(L) | 3.0-12.0 | ||
| 使用燃料 Applicable fuel | 柴油或煤油 Diesel or kerosene | ||
| 油箱容量(L) Tank capacity(L) | 100-140 | ||
| 额定电压(V) Rated voltage(V) | 三相 380 Three-phase 380 | ||
| 最大同时使用电力(KW) Maximum power consumption(KW) | 6.52 | ||
| 性能 Performance | 进料时间(分) Feeding time(Minute) | 稻 Paddy | 44-49 |
| 麦 Wheat | 45-50 | ||
| 排料时间(分) Discharging time(Minute) | 稻 Paddy | 50-60 | |
| 麦 Wheat | 40-50 | ||
| 降水率 Precipitation rate | 稻(/时) Paddy(/hour) | 0.7%-1.2% | |
| 麦(/时) Wheat(%/hour) | 0.8%-1.2% | ||
| 其他性能 Others | 安全装置 Safety devices | 满量报警 热继电器 风压开关 压力传感器 火焰监视器保险丝 热风温度传感器 籽粒温度传感器 外温度传感器 Full-range alarm, Thermal relay, Pressure switch, Pressure sensor, Flame Monitor fuse, Hot air temperature sensor, Seed temperature sensor, Outside temperature sensor | |
| 运转方式 Pattern of peration | 定时模式 自动模式 种子模式 Timing mode, Auto mode, Seed mode | ||
| 标准装置 Standard devices | 水分仪测仪 排尘机 梯子 排粮闸 Moisture meter, Dust discharging motor, Ladder,Grain discharging sluice | ||
| 选配热源 Optional heat | 热风炉 蒸汽换热器 燃气燃烧器 Hot stove, Steam heat exchanger, Burner |
