SK-T Pellet machine driven by tractor

Wood/biomass pellet machine driven by tractor, especially for working out of workshop, portable.

Application:

Flat die pellet mills are generally used for pellet production on a small to medium scale. Flat die pellet mills can process a wide range of biomass materials, for a range of applications. These include wood, straws, grasses and other biomass residues. And also for animal feedstuff .

Raw material for the pellet mill must have passed through sufficient size reduction before it can be placed in the pellet mill. The raw material must have a particle size of 3-5mm or below.

Key specification and quality warranty:

Heart parts of the pellet machine- die and roller are made by high alloy steel wear resistant material according to different materials, in order to have longer work lifetime.

Wood/biomass pellet machine with double layer dies , up and down dual-use, reduce buyer’s cost, so it can reach high capacity , also energy saving .

12months limited warranty for electric parts,

Average lifetime for die and rollers:

2000 hours for SK-350/450/550/800/1000,

800-1000hours for SK-200/250/300,

400hours for SK-105/120/150

1.

Model No.: SK-200T

Capacity: 100-150kgs/H

Drive way: PTO shaft

Diameter of pellets: 6-8mm

Pellet length: which can be adjusted by adjusting knife within range of 1-5cm .

Weight: 250kgs (without tractor)

Dimention: length: 450mm, width: 400mm, height: 1100mm (without tractor)

We sell it without tractor.

2.

Model No.: SK-250T

Capacity: 200-250kgs/H

Drive way: PTO shaft

Diameter of pellets:6-8mm

Pellet length: which can be adjusted by adjusting knife within range of 1-5cm .

Weight: 300kgs (without tractor)

Dimention: length: 550mm, width: 450mm, height: 1100mm (without tractor)

We sell it without tractor.

3.

(1) Model No.: SK-300T

Capacity: 250-300kgs/H

Power: 25-28HP

Drive way: PTO shaft

Diameter of pellets:6-20mm

Pellet length: which can be adjusted by adjusting knife within range of 1-5cm .

Diameter of the die: 300mm

Weight: 300kgs (without tractor)

Dimention: length: 600mm, width: 550mm, height: 1250mm (without tractor)

We sell it without tractor.

(2) Model No.: SK-300T

Capacity: 250-300kgs/H

Drive way : PTO shaft

Diameter of pellets:6-10mm

Pellet length: which can be adjusted by adjusting knife within range of 1-5cm .

Weight: 350kgs (without tractor)

Dimention: length: 600mm, width: 550mm, height: 1250mm (without tractor)

We sell it without tractor.

4.

Model No.: SK-350T

Capacity: 350-400kgs/H

Drive way : PTO shaft

Diameter of pellets:6-15mm

Pellet length: which can be adjusted by adjusting knife within range of 1-5cm .

Weight: 400kgs (without tractor)

Dimention: length: 650mm, width: 600mm, height: 1300mm (without tractor)

We sell it without tractor.
