Features:1.one video detection channel;
2.CIF resolution-low latency-MPEG-4 audio &video streaming;
3. Fully integrated and self-sustained video analysis and encoding appliance- no need for additional HW/SW;
4.Real time video analysis (DSP based)
5. High probability of detection, low false alarm rate (POD is 99%,FAR is less 1/day,)
6. 5 minutes setup process
Number of Intelligent Video Analysis Channels:1
IP Video Streaming:MPEG-4 SP and M-JPEG
Max Resolution per Channel:CIF
Bit Rate:CBR (128Kbps – 4Mbps), VBR
Ethernet (IEEE 802.3/802.3U):2x RJ-45 Interface
IN - Alarm Input:4 x Alarm inputs (from Dry Contacts)
OUT - Relay Output:2x Relay Output (rated load 1A@30VDC)
Voltage:12VDC
