Brand:Weima
Model:WM1100A
MOQ:1 Sets
Send Inquiry
| Tiller | Model | KS1000 |
| Dimension (mm) | 875×555×725 | |
| Net Weight (kg) | 85/90K | |
| Tilling Width (mm) | 700 | |
| Tilling Depth (mm) | ≥100 | |
| Gears | 1230-1 | |
| (Transmission method) | Gears | |
| Engine | Engine Model | WM168FB (Q shaft |
| Bore×Stroke(mm) | 68×54 | |
| Displacement (ml) | 196 | |
| Max Outputhp(kw)/rpm | 5.2(3.8)/3600 | |
| Rated Output hp(kw)/rpm | 4.8(3.5)/3600 | |
| Max Torque (N.m/rpm) | 10.5/2500 | |
| Starting method | Recoil start | |
| Ignition method | TCI | |
| Fuel tank capacity | 3.6 | |
| Fuel tank capacity | ||
| Engine type | OHV 25°,1 cylinder,4 strokes,Air cooled | |
| Air cleaner | Oil-bath | |
| Packing | Dimension (mm) | 850×660×450 |
| 20 FT(set) | 95 |
