Model HR-5000TA Power 5000W
Voltage 220V/380V 50/60HZ
Frequency 27.12MHZ
Rectifier SILICON DIODE
Oscillation tube 7T85RB
Max pressure 450KG
Gap between electrodes 160-200MM
The moving distance of active horn 60MM
Size of upper electrode 120?290mm
Pressure mode Pneumatic
Working plate 350*700mm
Welding time 0~10S Adjustable
Productivity 3000-4000times/8h
Net weight 350KG
Overall dimension 1720?1100?1500mm
character
Wide using in environmental protection plastic packing ,toothbrush packing,
environmental production dress-glue products with PVC,PVC coated fabric,TPU,PU,leather materials,
equally can process any materials needing welding
accurate-orientation, error±20um.
Adopting high sensitive anti-sparkle device NL5557 to avoid damaging the mould efficiency.
Operation mode: pneumatic or pedal style.
