Brand:RG
Quantity:15
Send Inquiry
C purlin roll forming machine,C purlin forming machine,
roll forming machine;
Technical Datas of the Machine:
Coil Width:170-430MM;
Suitable Coil Thickness: 2.0-3.0mm;
Coil Weight: 5 Ton;
Forming Stations: 13 stations;
Main line speed: 6- 10m/min;
Voltage: 380V/50Hz;
PLC Control System: Panasonic PLC Control the quantity, length automatically, touch screen;
Overall Dimensions: 7200mmx900mmx1400mm;
Toatal Weight: 6.5 T;
Main Motor Power: 18.5 KW;
