1- Material: Cylinder uses high strength and lightweight alloy manufacture ,elaborate design of both antiskid tooth to make sure when under stress won't
fall off;
2- Functions: Moving obstacles, top-up objects, create rescue channels and maintain object stable.
3- Features:
Can provide the Max. jacking force at 120KN
Bi-directional hydraulic lock and automatic reset valve operation, at working when occur unexpected encounters can ensure the operator security;
Short supporting time accelerates the rescue process
4- Applications: Highway, railway accident rescue, air crash and beach relief; Buildings and disaster relief


Rated Working Pressure 63MPa(630.000bar)
Max. Extending Force 120KN(12T)
Closed Length =350mm
Extending Scope 180mm
Length of Extending Bar?/?/? 100/175/275mm
Weight =10kg
Dimension(L*W*H) 350*260*90mm
