Brand:MINGHAO
Quantity:100
Send Inquiry
Max. drilling diameter Ømax=35mm (single drill) Ød=13mm (multi drill) Distance between spindle 1650mm
Max. drilling depth H max=60mm
Working pressure 0.5~0.6Mpa
Max. processing pitch 1650x672mm
Total power of motor 4.5kw
Min.processing pitch 130x32mm
Spindle speed 2840rpm
Total number of drilling shafts 63 pcs
Exterior of machine 2650x2500x1600mm
Total number of drilling rows 21x3 rows
Weight of machine 1500 kgs
Installing dia to the drill Ø10mm
