We supply Cummins KTA38-M marine engine from Chinese cummins-CCEC.Cummins KT38-M/KTA38-M0/KTA38-M1/KTA38-M2 marine engine, used for high speed commercial boats.
1 Model(900HP,1000HP,1200HP) KTA38-M0,KTA38-M1 KTA38-M2
2 Bore*Stroke 159mm*159mm
3 Cylinders V type 12 cylinder
4 Displacement 38L
5 exhaust type water cooled exhaust manifold
6 Aspiration Air-Intake,Turbocharged and Aftercooled
7 Rotation Direction Counter-clockwise (Facing the flywheel)
8 Electric system 24v
9 Fuel consumption 185L/Hour
10 Rated engine power 900HP,1000HP,1200HP
11 Rated engine speed 1800rpm
12 Peak Torque 3956N. M /1300rpm
13 Dimension 2500mm*1350mm *1963mm
14 Net weight 4500kg
