Features
High performance CMOS sensor and DSP technology
More than 1 Mega-Pixel resolution
Sharp, crystal-clear images
Auto white balance and auto exposure
Display higher speed than USB Camera
Support three couples of cross lines
Support OSD Menu
Can capture image to SD card with JPEG format
Specialized on industrial inspection and Microscopes

SXY-V20
Image Sensor: 1/3.2" CMOS, 2.0M pixel
Max Resolution : 1600×1200
Pixel Size: 3.6µmx3.6µm
S/N Ratio: >45dB
Sensitivity : 1.0V/lux-sec 550nm
ADC: 10bits
Lens Interface: Standard C/CS-Mount
Image frame Rate: 15fps @ 1600×1200; 15fps @ 1680×1050;15fps @ 1440×900; 15fps @ 1280×1024;
15fps @ 1280×800; 15fps @ 1024×768;30fps @ 800×600.
Operating system: Windows XP / Windows Vista / Windows 7
Output Interface: VGA Video Output
Image Store: No
Control Box: Support
Power supply: DC5V 1A
Work Temp: -5°C to +60°C
Size: 40mmx40mmx90mm
Weight: 235gram
