Application: Education, Industrial microscopy, Live cell image, Medical, Semiconductor inspection, MetrologySensor type: Color CMOS
Imaging sensor size 1/2.3"CMOS
Pixel size: 1.75µm×1.75µm
Effective pixels: 3488x2616
Max resolution: 3488x2616
Sensitivity: 0.31V/lux-sec 550nm
Dynamic Range: 39dB
Exposure Controls: Automatic
Gain Control: Automatic
White Balance: One shot automatic control
Image frame Rate: 2fps @ 3488×2616;6fps @ 1600×1200;20fps @ 1280×960;30fps @ 800×600;30fps @ 640×480
Control interface: USB 2.0
Lens Mount: Standard C/CS-mount
Control Software Operating System: Windows XP, Vista, 7 (32 bit and 64 bit)
Operating Temp: 0 to 50 °C
Dimensions: 55mmx70mmx90mm
Weight: 115g
