alert distance(Outdoor) 60M No. of beams 2beams
Detection mode 2beams blocked simultaneous
Optical source Infrared digital pulse beam
Response speed 50M/sec
Alarm output Wireless RF alarm signal
Power supply Solar power charged lithium battery
Power consumption ?0.4mA on the transmitter,?0.4mA on the receiver
RF frequency 2.4G(ZIGBEE)
RF transmission Up to 120m in the open space
Operation temperature& humidity -25?-55? 5%-95%RH(relative humidity)
Dimensions Refer to the diagram
Recharge currency by solar board =1mA under 1600Lx(more than 2000Lx in normal cloudy day)
Optical axis adjustment(H,V) 180°H(±90°),20°V(±10°)
Protection against dew, frost Calefaction housing(optional)
Material PC Resin
Net weight 1000g (transmitter + receiver
