Input/output specifications:Input voltages: 100 to 240V AC, 50 to 60Hz
Range voltage: 86 to 265V AC, 47 to 63Hz
Output power: 20 to 30W
Output voltage: 5.0 to 48.0V DC
Output current range: 500mA to 5.0A
Characteristics:
Compliant with the RoHS Directive
Meets energy efficiency level IV
These units provide a reliable output voltage
With short-circuit, over-voltage and over-current protections
100% burn in tested
DC socket (optional)
Plug holder: UL/CCC/VDE/KS/PSE
High-efficiency: mini 78%
Mtbf: 50,000 hours
Operating temperature: 0 to 40°C
Storage temperature: -20 to 85°c
Operating relative humidity: 5 to 95% RH
No minimum load
Color: black
Case: plastic ABS and PC UL94V-0
