Pressure range -100kPa~2kPa~60MPa
Measuring Medium The gas , liquid or vapor which is compatible with 316L stainless steel.
Pressure Type Gauge pressure, Absolute pressure, Sealed gauge pressure.
Power supply 12VDC~36VDC
Output signal 4~20mA, 0~5V,0~10V,1~5V,etc.
Accuracy ±0.5%FS(typical), ±0.25%FS
Long-term stability ±0.2%FS/Y
Temp. drift ±0.02%FS/?
Ambient temp. -40~85?
Medium temp. -40~125?
Compensated temp. 0~80?
Overpressure 200%FS
