Operating Speed 300 rpm* Number of Circuits 6, 12, 18, 24 ^^800
Voltage 250 VDC
Current Rating 10 AMPS / per circuit
Temperature Range -40 C ~ + 80 C
Contact Material Gold to Silver
Lead Size 22 gauge, Teflon
Lead Lengths 300 mm minimum
Torque Approx 50 cmg per circuit
Through Bore Φ 12.7 mm Φ 25.4mm Φ 38 mm Φ 50mm Φ 70mm
Φ 80mm Φ 96mm Φ 100mm Noise 100 milliohms max. Tested@ 6 VDC, 50 mA, 5 rpm
Options
Flange for set up
Longer lead lengths available
Current Rating2A, 10A, 15A-200A, available
Higher current and voltagecapacity
Signal and Powercircuitcombination
*The operational life of the unit is dependent upon rotational speed, environment and temperature
