Model#: HCT-400-L Outline Dimensions: L*W*H 1150*1050*1400mm
Total Weight: Approx 700kg
PCB Size Min: 50mm X50mm
Max:360mm X750mm
PCB Thickness: 0.5-3.0mm
PCB Convey Direction: From Left to right
Software: Windows XP
Display: LCD Monitor
Input Device: Mouse & Keyboard
No. of Camera: 5 Sets
Mark Point Recognition Gray scale & Multi - View Shape Recognition & Edge Detection
Positioning Way: MARK by Vision Alignment System
SMD Components: 0402 - IC<40mm (Max Height 12mm)
No. of Mounting Head: 4 Nozzles
No. of Feeders: 30 Units (8mm Feeders)
Accuracy: ±0.05mm (chip & IC)
Speed: 15200CPH (maximum)
Power Supply: Single phase, AC 220V (±10%), 50Hz
Maximum Power: 1.8 KW
Compressed Air: 0.7MPA
