Brand:Huayuan
Quantity:100000
Send Inquiry
Panel Type:TFT Panel Size:6.5"
Applications: Industrial control,Medical imaging,Bank Terminal and other
LCD display size
5.6 inch
LCD aspect ratio
4:3
Backlight
LED
Brightness
200cd/m2
Resolution
640×(RGB)×480
View angle(U,D,L,R)
(50/70/70/70)
LCD screen dimension
117.65(W)×88.43(H)×5.7(D)mm
Effective display area
101.568(W)×76.176(H)mm
Driver board dimension
102.0 (W)×50.0 (H))×7.9(D)mm
Power supply(power ripple<=0.3VP-P)
Min:DC9V;S:DC12V;Max:DC15V;
Working current(DC 12V power supply)
DC260mA±20mA
Power consume
3.12W(TYP)
Start time
1.5s
Operation temperature
-10°C~60°
Storage temperature
-20°C~70°C
