Brand:Huayuan
Quantity:100000
Send Inquiry
Display Mode Normally White,Transmissive Resolution 240 x 3 RGB x 320
Technology Type a-Si TFT active matrix
Pixel Pitch (mm) 0.18(H) x 0.18(V)
Pixel Configuration R.G.B. Vertical Stripe
Outline Dimension 50.0(W)x69.2(H)x3.5(D)
Active Area(mm) 43.2(W)x57.6(H) mm
Interface MCU 8080 8Bit/16Bit Parallel/SPI4
Viewing Direction 12:00
Surface treatment: Anti-Glare
Touch Panel Optional
LED Numbers 4 pcs (300cd/m2)
Color Depth 16.7M color
Operating Temperature -20~70°C
Storage Temperature -30~+80°C
