Price:Negotiable
Brand:TAILONG
Quantity:20000

Send Inquiry

Specifications
1)Size:MOQ is 1000m2, width X length X eave height, roof slope
2)Type:Single slope, double slope, muti slope; Single span, double span, Multi-span, single floor, double floors!
3) base:Cement and steel foundation bolts
4) Column and beam:Material Q345(S355JR)or Q235(S235JR) steel, all bolts connection! Straight cross-section or Variable cross-section!
5) Bracing: X or V or other type bracing made from angle, round pipe, etc
6) C or z purlin:Size from C120~C320, Z100~Z200
7) Roof and wall panel:Single colorfull corrugated steel sheet 0.326~0.8mm thick, YX28-205-820(820mm wide), sandwich panel with EPS, ROCK WOOL, PU etc insulation thickness around 50mm~150mm, width 950mm or 960mm!
8)Accessories:Semi-transparent skylight belts, Ventilators, down pipe, outer gutter, etc
9)Surface: Paint or hot dip galvanize!
10) Packing: Main steel frame without packing load in 40'OT, roof and wall panel load in 40'HQ!
