Rated voltage(VAC) 380 +/-10% Phases 3
Rated ampere(AAC) 120
Annual energyproduction(kWh) 120000
Rotor diameter(m) 13.8
Blade material GFRP
Start-up wind speed(m/s) 2.5
Direction (Lookingdownwind) Counterclockwise
Rated Wind speed(m/s) 12.5
Cut-out wind speed (m/s) 20
Survival wind speed(m/s) 45
Tilt angle 6
Rated RPM 59
Blade No. 3
Orientation drive type Auto/Manual
Efficiency 0.8
Nacelle weight (Tons) 2.8T
Frequency(Hz) 50/60
Safety devices :
-low speed shaft brake
- high speed shaft brake
-yawing brake
------------
control units
1.Mitsubishi PLC
2.outstanding anti-jamming
3.intelligent control has been achieved by combine various sensors
