Price:Negotiable
Brand:WINDWINGS
Quantity:300

Send Inquiry

Model FZY-WS-6000
Power 6000W
Wind turbine power 5kw
Solar pannel power 1000w
System DC voltage 240v
Recommended accumulators 4000AH
Working temperature from -40 °C to +60 °C
Charge control AIC (automatic intelligent control)


WIND TURBINE PARAMETER Wind turbine type PMG (on constant magnets)
Rotor diameter 4.5m
Blades quantity 3 pcs
Blades material FRP (composite material)
Rated speed 260r/min
Start wind speed 3m/s
Rated wind speed 10m/s
Working wind speed 3-25m/s
Security wind speed 40m/s
Speed regulation yaw& magnetic resistance
Tower type pull wire tubular tower
Tower height 9m
Weight(without tower) 130kgs


SOLAR PANEL PARAMETER Solar model 100w/24v 10pcs
Wp max (W) 100
Vmp(V) 35
Imp(A) 2.86
Voc(V) 43
Isc(A) 3.02
Size(mm) 1580×808×35
Weight(KGS) 15.5
