Model Inner diameter Feed diameter Overflow diameter Angle of cone Max size Separation size(micron) Feed pressure(Mpa) Treating capacity(m³/h)
2? 50mm 16x6mm 12mm 6º 0.3mm 5-30 0.1-0.4 1.6
3? 75mm 15-17mm 22mm 7º,15º 0.6mm 20-405-74.5 0.1-0.5 2-5
4? 100mm 26x16mm 40mm 20º 1mm 20-60 0.1-0.3 8
5? 150mm 30x26mm 40mm 20º 1.5mm 30-100 0.05-0.3 15
6? 200mm 60x30mm 50-80mm 20º 2mm 40-100 0.05-0.25 40
8? 250mm 95x50mm 80-106mm 20º 3mm 40-100 0.05-0.25 60
10? 300mm 64mm 120-135mm 20º 4.5mm 40-100 0.03-0.25 70
12? 350mm 80mm 95-115mm 19º 7mm 40-110 0.03-0.25 90
